Clutch Kit Fits John Deere 70 720 730 Disc Pulley Overhaul Rebuild Repair AA6129

Name: Clutch Kit Fits John Deere 70 720 730 Disc Pulley Overhaul Rebuild Repair AA6129
SKU: AA6129R-C614R-KIT
Price: 186.99 USD
Availability: InStock

Clutch Kit Fits John Deere 70 720 730 Disc Pulley Overhaul Rebuild Repair AA6129

$186.99 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

One New Aftermarket Replacement Clutch Kit

Fits John Deere Models: 70, 720, 730

Kit Contains:
(2) AA6129R Clutch Pulleys
(2) C614R Clutch Discs
(1) RE29790 Brake Pad Pulley
(3) A352R Clutch Disc Adjusting Springs
(3) 14H862 Clutch Adjusting Nuts
(3) JDS1626 Clutch Pressure Plate Spring (Fits Belleville) Washers

Tech Info:
The pulley clutch disc are 0.393" thick. Two are need per tractor.

The floating clutch facing discs are 10" (OD) x 6 3/4" (ID) x 0.15" (thick). Two are needed per tractor.

The belt pulley brake lining is a non-asbestos lining with countersunk brass rivets.

The clutch disc adjusting springs measure 1.915" long and the wire thickness measures 0.12". The springs mount to the outer cast iron adjusting disc. Three needed per tractor.

The clutch adjusting nuts are 9/16" slotted hex nuts, 18 NF, Grade 5 and three are used per tractor.

Washers should be torqued initially to 15 FT pounds and adjusted as needed. The washer mounts between slotted adjusting nut and pressure plate.

Models This Part Fits:

720, 730

Additional Information:

(2) Facing Clutch Pulley 10" disc outside diameter 0.393" thick Replaces Part Numbers: AA5082R, AA6129 (2) Facing Clutch Disc 10" outside diameter (OD) 6-3/4" inside diameter (ID) 0.150" thick The side with the grooves faces the driving disc 1-5/8" lining width Replaces Part Numbers: R90215, C614R (1) Brake Pad Pulley Non-asbestos lining with countersunk brass rivets Replaces Part Numbers: AB4748R, AF4748R, RE29790 (3) Clutch Disc Adjusting Spring 1.915" long 0.740" outside diameter 0.500" inside diameter 0.120" wire thickness The clutch disc adjusting spring mounts to the outer cast iron adjusting disc 3 springs used per tractor Replaces Part Numbers: A352R (3) Clutch Adjusting Nut 9/16" - 18 NF Grade 5 Slotted hex nut, 9/16" 3 used per tractor Replaces Part Numbers: 14H862, AD2850R, D2789R, R20228 (3) Clutch Pressure Plate Spring (Belleville) Washer 0.572" inside diameter 0.937" outside diameter 0.035" thick Spring steel Torque initially to 15 FT pounds, then adjust as needed Use to smooth out the hand clutch engagement 3 used per tractor Replaces part Numbers: JDS1626
